Products Screw vacuum pumps AFK-SDF Series Screw Vacuum Pumps AFK-SDF70 air-cooled screw vacuum pump

AFK-SDF70 air-cooled screw vacuum pump

Motor power(50Hz):3.0Kw

Pumping speed (50/60Hz): 70 m3/h

Ultimate vacuum: ≤10Pa

Do you want to know more?

If you need to know more CAD data or 3D models, please contact AIFIKER directly:

Drawings

Tech. consult.

400-0578-579
  • Specification parameters
  • Installation dim. drawing
  • Get a quote
parametersunitAFK-SDF70
Pumping speedm3/h70
Ultimate pressurePa≤10
Rotational speedrpm2850
Noise leveldB(A)75
Motor powerKw3.0
Air inlet
KF40
Exhaust port
KF40
Pump head weightKg110
Overall dimensions(L*W*H)mm960*450*480
