Products Screw vacuum pumps AFK-SDF Series Screw Vacuum Pumps AFK-SDF20 air-cooled screw vacuum pump

AFK-SDF20 air-cooled screw vacuum pump

Motor power(50Hz):1.1Kw

Pumping speed (50/60Hz): 20 m3/h

Ultimate vacuum: ≤5Pa

Do you want to know more?

If you need to know more CAD data or 3D models, please contact AIFIKER directly:

Drawings

Tech. consult.

400-0578-579
  • Specification parameters
  • Installation dim. drawing
  • Get a quote
parametersunitAFK-SDF20
Pumping speedm3/h20
Ultimate pressurePa≤5
Rotational speedrpm2840
Noise leveldB(A)72
Motor powerKw1.1
Air inlet
KF25
Exhaust port
KF25
Pump head weightKg50
Overall dimensions(L*W*H)mm900*400*430
