AFK-S063 single-stage rotary vane vacuum pump

Motor power(50Hz):2.2/3.0

Pumping speed (50/60Hz): 63 m3/h

Ultimate vacuum: 0.1~0.5mbar

Do you want to know more?

If you need to know more CAD data or 3D models, please contact AIFIKER directly:

Drawings

Tech. consult.

400-0578-579
  • Specification parameters
  • Installation dim. drawing
  • Get a quote
parametersUNITAFK-S063
Rated flow rate50Hz63 m3/h
60Hz78 m3/h
Ultimate vacuummbar0.1~0.5
Motor power[50Hz/60Hz]Kw2.2/3.0
Rotational speed[50Hz/60Hz]r/min1440/1720
Noise level[50Hz/60Hz] (ISO 2151)dB(A)64/65
Inlet diameter
G1 1/4
Exhaust diameter
G1 1/4
Oil injection volumeL2.0
Weight (~)kg55/72
