Motor power(50Hz):11Kw
Pumping speed (50/60Hz): 2590 m3/h
Ultimate vacuum: 80mbar
Do you want to know more?
If you need to know more CAD data or 3D models, please contact AIFIKER directly:
| parameters | unit | AFK-MB2600 |
|---|---|---|
| Pumping speed(50Hz) | 50Hz | 2590m3/h |
| Pumping speed(60Hz) | 50Hz | 3110m3/h |
| Air inlet | DN | ISO160 |
| Exhaust port | DN | ISO100 |
| Pump pressure difference（50Hz） | mbar/Pa | 80/8000 |
| Pump pressure difference（60Hz） | mbar/Pa | 67/6700 |
| Motor power | Kw | 11.0 |
| Rotational speed（50Hz） | rpm | 2900 |
| Rotational speed（60Hz） | rpm | 3500 |
| Oil injection volume for gearbox | L | 3.5 |
| Oil injection volume for coupling cover | L | 6.5 |
| Oil injection volume for shaft seal box | L | 0.15 |
| Water-cooling requirements | L/h | 250 |
| Weight (~) | kg | 400 |
